Capacity：3000 KG
Drive Motor：1300 W
Lifting Motor：800 W
Fork Length：1160 mm
Fork Width：685 mm / 550 mm
| Price | Action |
|---|---|
| Fork Length | 1150mm |
| Fork Width | 550mm |
| Loading Capacity | 2.0T/2.5T/3T/5T |
Also available at competitive prices from authorized retailers, with optional Premium delivery for expedited shipping.
| Brand Name | IVITAL | Product Name | Fully Electric Pallet Truck |
|---|---|---|---|
| Fork Width | 550/685mm | Fork Length | 1160mm |
| Loading Capacity | 3000kg | Minimum Fork Height | 85MM |
| Maximum Fork Height | 200MM | Net Weight of the Whole Vehicle | 213KG |
| Battery Specification | Tianneng Lead -Acid 48V32A/48V20A | Drive Wheel Specification | Polyurethane 160*55MM |
| Drive Motor | 1300W | Lifting Motor | 800W |
| Operation Mode | Electric Travel, Electric Lifting, Electric Lowering | Minimum Turning Radius | 1550MM |
| Braking | Electromagnetic Brake + Electronic Brake | Climbing Capacity (Loaded/Unloaded%) | Loaded/Unloaded %: 8/16 |
High Efficiency Warehouse Electric Carrier for Heavy-Duty Material Handling
IVITAL EV-3.0-C Series fully electric pallet truck is designed for modern warehouses, logistics centers, manufacturing plants and distribution facilities. With a 3000KG load capacity, powerful electric drive system and ergonomic design, it provides an efficient, safe and labor-saving solution for pallet transportation.
Equipped with a 48V lead-acid battery system, 1300W drive motor and 800W lifting motor, this electric pallet truck delivers strong performance, stable operation and excellent durability for intensive daily handling tasks.
| Model | EV-3.0-C Series |
|---|---|
| Maximum Load Capacity | 3000 KG |
| Battery Specification | Tianneng Lead-Acid Battery 48V32A / 48V20A |
| Drive Wheel | Polyurethane 160 × 55 mm |
| Drive Motor | 1300 W |
| Lifting Motor | 800 W |
| Fork Length | 1160 mm |
| Fork Height | Min. 85 mm / Max. 200 mm |
| Fork Width | 685 mm / 550 mm |
| Climbing Capacity | Loaded 8% / Unloaded 16% |
| Operation Mode | Electric Travel, Electric Lifting, Electric Lowering |
| Turning Radius | 1550 mm |
| Braking System | Electromagnetic Brake + Electronic Brake |
Electric travel, lifting and lowering functions reduce labor intensity and improve handling efficiency.
Designed for heavy pallet handling in warehouses and industrial areas.
Stable 48V battery power provides reliable performance for daily operations.
Electromagnetic brake and electronic brake ensure safe operation.
We specialize in manufacturing industrial material handling and warehouse equipment, including pallet trucks, stackers, forklifts, and hydraulic lifting tables. Our products are designed for efficient cargo handling, warehouse operations, and industrial lifting applications worldwide.
